Table 17 DD990 cabling (mixed ES20 and ES30): ES20 4-6 (continued)
Rack 2 Rack 1 Rack 2 Rack 1 Rack 2 Rack 1
ES30 V5.1 ES20 V1.1 ES30 V5.1 ES20 V1.1 ES30 V5.1 ES20 V1.1
4 ES20 5 ES20 6 ES20
Those entries in the table marked with an asterisk (*) are to be added last.
Table 18 DD990 cabling (mixed ES20 and ES30): ES20 7-9
Rack 2 Rack 1 Rack 2 Rack 1 Rack 2 Rack 1
ES30 V6.4 ES30 V3.5 ES30 V6.4 ES30 V3.4 ES30 V4.5 ES30 V4.3
ES30 V6.3 ES30 V3.4 ES30 V6.3 ES30 V3.3 ES30 V4.4 ES30 V4.2
ES30 V6.2 ES30 V3.3 ES30 V6.2 ES30 V3.2 ES30 V6.5* ES30 V4.1
ES30 V6.1 ES30 V3.2 ES30 V6.1 ES30 V3.1 ES30 V6.4 ES20 V3.3
ES30 V5.4 ES30 V3.1 ES30 V5.4 ES20 V2.4 ES30 V6.3 ES20 V3.2
ES30 V5.3 ES20 V2.4 ES30 V5.3 ES20 V2.3 ES30 V6.2 ES20 V3.1
ES30 V5.2 ES20 V2.3 ES30 V5.2 ES20 V2.2 ES30 V6.1 ES20 V2.3
ES30 V5.1 ES20 V2.2 ES30 V5.1 ES20 V2.1 ES30 V5.5* ES20 V2.2
Empty DD990 Empty DD990 Empty DD990
ES30 V4.4 ES20 V2.1 ES30 V4.4 ES20 V1.4 ES30 V5.4 ES20 V2.1
ES30 V4.3 ES20 V1.3 ES30 V4.3 ES20 V1.3 ES30 V5.3 ES20 V1.3
ES30 V4.2 ES20 V1.2 ES30 V4.2 ES20 V1.2 ES30 V5.2 ES20 V1.2
ES30 V4.1 ES20 V1.1 ES30 V4.1 ES20 V1.1 ES30 V5.1 ES20 V1.1
7 ES20 8 ES20 9 ES20
Those entries in the table marked with an asterisk (*) are to be added last.
Table 19 DD990 cabling (mixed ES20 and ES30): ES20 10-12
Rack 2 Rack 1 Rack 2 Rack 1 Rack 2 Rack 1
ES30 V4.4 ES30 V4.2 ES30 V6.4 ES30 V6.5 ES30 V6.4 ES20 V3.4
ES30 V4.3 ES30 V4.1 ES30 V6.3 ES20 V3.3 ES30 V6.3 ES20 V3.3
ES30 V6.5* ES20 V3.3 ES30 V6.2 ES20 V3.2 ES30 V6.2 ES20 V3.2
ES30 V6.4 ES20 V3.2 ES30 V6.1 ES20 V3.1 ES30 V6.1 ES20 V3.1
ES30 V6.3 ES20 V3.1 ES30 V5.4 ES20 V2.4 ES30 V5.4 ES20 V2.4
ES30 V6.2 ES20 V2.3 ES30 V5.3 ES20 V2.3 ES30 V5.3 ES20 V2.3
Installing the Shelves
DD990 cabling 41
