Note
The DD9500 system running DD OS 5.6 does not support any ES20 shelves.
Note
The racks are filled from bottom up.
The cabling diagrams in this section show the maximum configurations for the
DD9500 and DD9800 systems. Not all systems will have all the disk shelves shown in
the diagrams.
Installing the Shelves
DD9500 and DD9800 cabling 67
