Table 12 C-Series (Gen2) upgrades (continued)
Model number Disk upgrade (to the next
higher model)
Hardware upgrade (to
the next higher model)
11 Phoenix-12 Compute
Servers
12 integrated disks One server chassis (four
nodes)
12 Phoenix-12 Compute
Servers (maximum
configuration)
12 integrated disks One server chassis (four
nodes)
C-Series Appliance (Gen1) configurations and upgrade
paths
Describes the first generation C-Series ECS Appliance configurations and the upgrade
paths between the configurations. Gen1 hardware became generally available in March
2015.
C-Series (Gen1) configurations
The C-Series Appliance is a dense compute solution using commodity hardware.
Table 13
C-Series (Gen1) configurations
Phoenix-12 Compute
Servers
Nodes Storage
capacity
Switches
2 (minimum
configuration)
8 144TB One private and two public
3 12 216TB One private and two public
4 16 288TB One private and two public
5 20 360TB One private and two public
6 24 432TB One private and two public
7 28 504TB Two private and four public
8 32 576TB Two private and four public
9 36 648TB Two private and four public
10 40 720TB Two private and four public
11 44 792TB Two private and four public
12 (maximum
configuration)
48 864TB Two private and four public
C-Series (Gen1) upgrade paths
C-Series upgrades consist of the disks and infrastructure hardware that is needed to
move from the existing model number to the next higher model number. To upgrade
by more than one model level, order the upgrades for each level and apply them in one
service call.
Hardware Components and Configurations
22 D- and U-Series Hardware Guide
