Dell EMC ECS U Series - Enclosure Leds; Enclosure Leds from the Front; Pikes Peak Chassis with I;O Module and Power Supplies Removed, Sleds Extended

Figure 18 Pikes Peak chassis with I/O module and power supplies removed, sleds extended
Figure 19 Enclosure LEDs from the front
Table 32 Enclosure LEDs
LED Color State Description
Enclosure "OK" Green Solid Enclosure operating normally
Enclosure Fail Yellow Fast flashing Enclosure failure
Enclosure Identify Blue Slow flashing Enclosure received an identify
command
Disk Drives
Pikes Peak (dense storage) 49
