Item Button or Display Description
1. · Press and hold the right button to
increase scrolling speed.
2. Release the button To stop scrolling,
release the button.
NOTE: The display stops scrolling
when the button is released. After
45 s of inactivity, the display starts
scrolling.
4 LCD Display Displays system information, status, and
error messages or iDRAC address
View the Home screen
The Home screen displays user-configurable information about the system. This screen is displayed during normal system operation when
there are no status messages or errors. When the system is off and there are no errors, the LCD enters standby mode after five minutes
of inactivity. Press any button on the LCD display to turn it on.
1. To view the Home screen, press one of the three navigation buttons (Select, Left, or Right).
2. To go to the Home screen from another menu, complete the following steps:
a. Press and hold the navigation button until the up arrow is displayed.
b. Go to the Home icon by using the up arrow.
c. On the Home screen, press the Select button to enter the main menu.
d. Select the Home icon.
Setup menu
NOTE: When you select an option in the Setup menu, confirm the option before going to the next action.
Option Description
iDRAC Select DHCP or Static IP to configure the network mode. If Static
IP is selected, the available fields are IP, Subnet (Sub), and
Gateway (Gtw). Select Setup DNS to enable DNS and to view
domain addresses. Two separate DNS entries are available.
Set error Select SEL to view LCD error messages in a format that matches
the IPMI description in the SEL. You can match an LCD message
with an SEL entry. Select Simple to view LCD error messages in a
simplified description. For information about the generated event
and error messages in the system firmware and agents that
monitor system components, see the Error Code Lookup page, at
qrl.dell.com.
Set home Select the default information for the Home screen.
View menu
NOTE: When you select an option in the View menu, confirm the option before going to the next action.
Option Description
iDRAC IP Displays the IPv4 or IPv6 addresses for iDRAC9. Addresses include
DNS (Primary and Secondary), Gateway, IP, and Subnet (IPv6
does not have Subnet).
MAC Displays the MAC addresses for iDRAC, iSCSI, or Network devices
F200 and F600 node configuration 17
