Node installation
This document describes how to install F200 and F600 nodes into an equipment cabinet.
Topics:
• Before you begin
• Rail kit components
• Install the rails
• Secure the rail assemblies to the cabinet
• Install the system in the cabinet
• Install the front bezel
• Connect and route cords and cables
• Configure the Integrated Dell Remote Access Controller (iDRAC)
Before you begin
WARNING: Before you begin, read and follow the safety instructions in any Safety, Environmental, and Regulatory
information document shipped with the system.
WARNING: To avoid injury, do not attempt to lift the system by yourself.
NOTE: The figures in this document do not represent a specific system.
NOTE: The rail kit is compatible with square, unthreaded round, and threaded round hole racks.
Rail kit components
The sliding rail assemblies are used to secure the node in the cabinet, and extended from the cabinet so that the system cover can be
removed to access the internal FRUs. The A10 sliding rail assembly (1U) is used for installation of the F200 and F600 nodes.
2
6 Node installation
