Dell EMC Virtual Edge Platform 1405 Series User Manual

Introduction
This document provides the operating system installation steps for the Dell EMC Virtual Edge Platform (VEP) 1405 series of systems. The
steps that are provided have been tested and verified on VEP1405 devices using the following information:
Table 1. Ubuntu operating system information
Feature Description
Ubuntu operating system image ubuntu-18.10-live-server-amd64.iso
Red Hat Enterprise Linux (RHEL) operating system image rhel-server-7.5-x86_64-dvd.iso
ADVA operating system image SVCS_connector-18.3.2.61-18.3-standard.87.iso
The VEP1445 16-core device configuration before installing the Ubuntu operating system is as follows:
Table 2. VEP1445 device configuration prior to the installation of Ubuntu
Feature Description
VEP1445 operating system DIAG operating system version 3.43.3.81-13
BIOS version 3.48.0.9-2
CPLD version 0.1
Topics:
• Chassis physical design
Chassis physical design
Table 3. Available system configurations
CPU Description
4-core
• 8G DDR4
• 16G eMMC
• 120G SSD
• 2x2 Wi-Fi
• 6x1G RJ45 plus 2x10G SFP+
• Single fan
8-core
• 16G DDR4
• 16G eMMC
• 240G SSD
• 2x2 Wi-Fi
• 6x1G RJ45 plus 2x10G SFP+
• Two fans
16-core
• 32G DDR4
• 16G eMMC
• 240G SSD
• 2x2 Wi-Fi
• 6x1G RJ45 plus 2x10G SFP+
• Two fans
1
4 Introduction
