Dell 13 7000 2-in-1 - Screw List

Screw list
The following table provides the list of screws that are used for securing dierent
components.
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Bottom cover Palm-rest
assembly
M2.5x5 9
Battery Palm-rest
assembly
M2x3 4
Fan Keyboard bracket M2x3 2
Wireless card Keyboard bracket M2x3 1
Power-adapter
port
Palm-rest
assembly
M2x3 1
Display
assembly
Palm-rest
assembly
M2.5x5 6
I/O Board Keyboard bracket M2x2 1
Palm-rest
assembly
1
Solid-state drive Keyboard bracket M2x3 1
Type-C port
bracket
System board M2x3 1
Palm-rest
assembly
1
Touchpad Palm-rest
assembly
M2x2 4
System board Keyboard bracket M2x2 2
