10 Connecting Your Projector
2
Connecting Your Projector
1 WiFi USB (Type A) connector 11 +12 V DC out connector
2 USB Type B connector for USB
Display
12 Security cable slot
3 USB Type A connector for USB
Viewer
13 Component Video input
connector
4 RJ45 connector 14 Power cord connector
5 S-Video connector 15 VGA-A output (monitor loop-
through) connector
6 Composite Video connector 16 VGA-B input (D-sub) connector
7 RS232 (D-sub) connector 17 VGA-A input (D-sub) connector
8 Mini USB (Mini Type B)
connector for remote control
18 HDMI-B connector
9 Audio output connector 19 HDMI-A connector
10 Audio input connector
3 4 5 6 7
8
14 12
1
2
13
910
19
15
161718
11
