Dell Alienware 15 R4 - Page 13

Component Secured to Screw type Quantity Screw image
I/O board Palm-rest
assembly
M2.5x5 2
Touch-pad
bracket
Palm-rest
assembly
M2x3 5
Display
assembly
Palm-rest
assembly
M2.5x5 6
Display panel Display back-
cover
M2x3 4
Power-adapter
port bracket
Palm-rest
assembly
M2x3 1
Power-button
board
Palm-rest
assembly
M2x3 2
System-board
assembly
Palm-rest
assembly
M2.5x5 7
Keyboard
bracket
Palm-rest
assembly
M2x3 15
Wireless-card
bracket
Computer base M2x3 1
13
