Removing the touchpad
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
3 Follow the procedure from step 1 to step 3 in "Removing the hard drive".
4 Remove the solid-state drive.
5 Remove the rear-I/O cover.
6 Remove the computer base.
7 Remove the battery.
Procedure
1 Open the latch and disconnect the touchpad cable from the system board.
2 Open the latches and disconnect the other end of the touchpad cable and
the touchpad-buttons cable from the touchpad.
3 Remove the ve screws (M2x3) that secure the touchpad bracket to the
palm-rest assembly.
59
