3 Replace the 15 screws (M2x3) that secure the keyboard bracket to the palm-
rest assembly.
Post-requisites
1 Follow the procedure from step 2 to step 16 in “Replacing the system board”.
2 Replace the memory modules.
3 Replace the battery.
4 Replace the computer base.
5 Replace the rear-I/O cover.
6 Replace the solid-state drive.
7 Follow the procedure from step 4 to step 6 in "Replacing the hard drive".
8 Replace the wireless card.
9 Replace the base cover.
87

Dell Alienware 15 R4 Specifications

General

Wireless	Killer 1550 802.11ac 2x2 WiFi and Bluetooth 5.0
Display	15.6-inch FHD (1920 x 1080)
Processor	8th Generation Intel Core i5 or i7
Graphics	NVIDIA GeForce GTX 1070
RAM	Up to 32GB DDR4
Storage	Up to 1TB PCIe SSD
Operating System	Windows 10
Weight	3.49 kg (7.7 lbs)
Display Refresh Rate	60Hz
Display Type	IPS
Ports	1 x HDMI 2.0, 1 x Mini DisplayPort 1.3, 1 x Alienware Graphics Amplifier Port, 1 x RJ-45 Killer E2500 Gigabit Ethernet, 1 x Headphone/Microphone Combo Jack
