Dell Alienware 15 R4 User Manual

Removing the solid-state drive
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your computer.
For more safety best practices, see the Regulatory Compliance home
page at
www.dell.com/regulatory_compliance.
CAUTION: Solid-state drives are fragile. Exercise care when handling the
solid-state drive.
CAUTION: To avoid data loss, do not remove the solid-state drive while
the computer is in sleep or on state.
Prerequisites
Remove the base cover.
Procedure
1 Remove the screw (M2x3) that secures the solid-state drive shield and solid-
state drive to the computer base.
2 Peel o the solid-state drive shield from the solid-state drive.
NOTE: Solid-state drive shield is applicable to computers that are
shipped with 1 TB solid-state drive.
32

Dell Alienware 15 R4 Specifications

General

Wireless	Killer 1550 802.11ac 2x2 WiFi and Bluetooth 5.0
Display	15.6-inch FHD (1920 x 1080)
Processor	8th Generation Intel Core i5 or i7
Graphics	NVIDIA GeForce GTX 1070
RAM	Up to 32GB DDR4
Storage	Up to 1TB PCIe SSD
Operating System	Windows 10
Weight	3.49 kg (7.7 lbs)
Display Refresh Rate	60Hz
Display Type	IPS
Ports	1 x HDMI 2.0, 1 x Mini DisplayPort 1.3, 1 x Alienware Graphics Amplifier Port, 1 x RJ-45 Killer E2500 Gigabit Ethernet, 1 x Headphone/Microphone Combo Jack
