Replacing the power-button
board
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before working inside your computer.
After working inside your computer, follow the instructions
in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the power-button board with the screw holes on
the palm-rest assembly.
2 Replace the screws that secure the power-button board to the palm-rest
assembly.
3 Connect the power-button board cable to the power-button board.
4 Slide the touch-pad cable and the status-light cable into their respective
connectors on the power-button board and press down the latches to
secure the cables.
Post-requisites
1 Follow the procedure from step 5 to step 11 in “Replacing the palm rest”.
2 Replace the base panel.
39
