Removing the display
assembly
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before working inside your computer.
After working inside your computer, follow the instructions
in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base panel.
2 Follow the procedure from step 1 to step 9 in “Removing the palm rest”.
Procedure
1 Close the display and turn the computer over.
2 Remove the screws that secure the display assembly to the computer
base.
3 Remove the screw that secures the wireless-card bracket and the wireless
card to the system board.
4 Lift the wireless-card bracket off the wireless card.
52
