10 | About your monitor
Side view
2
3
4
5
6
7
8
9
11
12
1
10
Label Description Use
1 Audio line-out port Connect to external audio peripherals.
Only supports 2-channel audio.
NOTE:
The audio line-out port does not
support headphones.
2 Audio line-in port Analog audio (two channel) input.
3 VGA connector Connect your computer with VGA cable.
4 DP connector Connect your computer with DP cable.
5 HDMI 1 connector
Connect your computer with HDMI cable.
6 HDMI 2 connector
7 USB dedicated
charging port
USB 3.0 with 10 W - Power supply (5V/2.0A)
8 USB 3.0
downstream port
Connect your USB device.
You can only use this connector after you have
connected the USB cable to the computer and
USB upstream connector on the monitor.

Other manuals for Dell C5519Q

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell C5519Q and is the answer not in the manual?

Dell C5519Q Specifications

General IconGeneral
Hardness3H
LED typeLED light bar system
Color gamut72 %
Pixel pitch0.315 x 0.315 mm
Response time8 ms
Display diagonal55 \
Display brightness350 cd/m²
Display technologyLCD
Native aspect ratio16:9
Native refresh rate60 Hz
Vertical scan range23 - 80 Hz
Horizontal scan range30 - 160 kHz
Supported video modes480p, 576p, 720p, 1080i, 1080p, 2160p
Contrast ratio (typical)4000:1
Display number of colors1.073 billion colors
Display diagonal (metric)139.7 cm
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 900, 1920 x 1080 (HD 1080), 3840 x 2160
CertificationCEL, WEEE, ErP, TCO, BFR/PVC free
AC input voltage100 - 240 V
Heat dissipation307.8 BTU/h
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)200 W
Power consumption (off)0.3 W
Power consumption (standby)0.4 W
Power consumption (typical)100 W
Operating altitude0 - 5000 m
Non-operating altitude5000 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 80 %
Package weight27570 g
USB version3.2 Gen 1 (3.1 Gen 1)
Ethernet LANYes
Audio (L/R) in2
USB connector typeUSB Type-A
USB ports quantity4
DVI-I ports quantity0
Ethernet LAN (RJ-45) ports1
Cables includedAC, DisplayPort, HDMI, USB, VGA
OrientationVertical
Product colorBlack
Product designDigital signage flat panel
Bezel width (side)15.7 mm
Placement supportedIndoor
Bezel width (bottom)25.55 mm
Panel mounting interface400 x 400 mm
RMS rated power20 W
PurposeCorporate
Sustainability certificatesRoHS, ENERGY STAR
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth64.8 mm
Width1241 mm
Height721.5 mm
Weight20500 g
