Dell C5519Q User Manual

About your monitor | 9
Back view
1
2
3
4
5
6
7
Q40G055N-700-04A
DELL C5519Q
8
XXXXX
XXXXXXXXXXXXXX
R-REM-TPF-C5519Qc
제조자/신청인:TPV Electronics (Fujian) Co., Ltd.
080-200-3800
SVC Tag:
xxxxxxx
Express Service
Code:
xxx xxx xxx x
S/N: XXXXXXXX
XXXXXXXXXXXX
XXX
Date of Mfg/生产日期/生產日期: January. 2018
R33037
RoHS
デ
入力:100V,2.5 A, 50/60 Hz
UA.TR.001
IS 13252(Part1)/
IEC 60950-1
R-41018660
液晶显示器
型号: C5519Q
输入电源:100-240V 50/60Hz,2.5A
中国制造
Flat Panel Monitor /Monitor Plano Panel /
Moniteur écran plat /液晶顯示器
Model No. /Modelo /N°de modelo /型號: C5519Qc
Input Rang /Entrade /Daya Tegangan:
100-240V 50/60Hz,2.5A
輸入電源:交流電壓100-240伏特,2.5安培,50/60赫茲
Raheen Business Park Limerick Ireland (for EU Only)
www.dell.com/regulatory_compliance
xxxxxx-xx
Consumo de energía en operación: XX.X Wh
Удельная мощность рабочего режима - X.XXX Вт/см²
Потребляемая мощность изделием в режиме ожидания - X.XX Вт
Потребляемая мощность изделием в выключенном режиме - X.XX Вт
This device complies with part 15 of the FCC Rules.
Operaon is subject to the following two condions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operaon.
Apparatet må lkoples jordet skkontakt.
Apparaten skall anslutas ll jordat uag.
Laite on liiteävä suojakoskemilla varusteuun pistorasiaan.
Apparatets skprop skal lslues en skkontakt med jord,
som giver forbindelse l skproppens jord.
The equipment must be connected to an earthed mains socket-outlet.
L'appareil doit être branché sur une prise de
courant munie d'une mise à la terre.
CAN ICES-3 (B)/NMB-3(B) 警語: 使用過度恐傷害視力。
Made in China/сделанный в Китай /Fabriqué en Chine /中國製造
Label Description Use
1 VESA mounting holes (400
mm x 400 mm)
To mount the monitor.
2 Regulatory label List of approved regulatory labels.
3 AC power connector To connect the monitor power cable.
4 Function buttons (For more
information, see Operating the
monitor)
Use the keys on the back of the monitor
to adjust the image settings.
5 Security lock slot Secures monitor with security lock.
6 Screw Hole For accessory mounting.
7 Cable clips position Sticking cable clips on these positions to
organize the cables.

Dell C5519Q Specifications

General

Hardness	3H
LED type	LED light bar system
Color gamut	72 %
Pixel pitch	0.315 x 0.315 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Vertical scan range	23 - 80 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	480p, 576p, 720p, 1080i, 1080p, 2160p
Contrast ratio (typical)	4000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	139.7 cm
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 900, 1920 x 1080 (HD 1080), 3840 x 2160
Certification	CEL, WEEE, ErP, TCO, BFR/PVC free
AC input voltage	100 - 240 V
Heat dissipation	307.8 BTU/h
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	200 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	100 W
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package weight	27570 g
USB version	3.2 Gen 1 (3.1 Gen 1)
Ethernet LAN	Yes
Audio (L/R) in	2
USB connector type	USB Type-A
USB ports quantity	4
DVI-I ports quantity	0
Ethernet LAN (RJ-45) ports	1
Cables included	AC, DisplayPort, HDMI, USB, VGA
Orientation	Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	15.7 mm
Placement supported	Indoor
Bezel width (bottom)	25.55 mm
Panel mounting interface	400 x 400 mm
RMS rated power	20 W
Purpose	Corporate
Sustainability certificates	RoHS, ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	64.8 mm
Width	1241 mm
Height	721.5 mm
Weight	20500 g
