Dell C5519Q User Manual

Setting up the monitor | 25
Inserting the batteries in the remote control
The remote control is powered by two 1.5V AAA batteries.
To install or replace batteries:
1.
Press and then slide the cover to open it.
2.
Align the batteries according to the (+) and (–) indications inside the battery
compartment.
3.
Replace the cover.
CAUTION: The incorrect use of batteries can result in leaks or
bursting. Be sure to follow these instructions:
• Place “AAA” batteries matching the (+) and (–) signs on each battery to the
(+) and (–) signs of the battery compartment.
• Do not mix battery types.
• Do not combine new batteries with used ones. It causes shorter life or
leakage of batteries.
• Remove the dead batteries immediately to prevent them from liquid leaking
in the battery compartment. Do not touch exposed battery acid, as it can
damage your skin.
NOTE: If you do not intend to use the remote control for a long period,
remove the batteries.

Dell C5519Q Specifications

General

Hardness	3H
LED type	LED light bar system
Color gamut	72 %
Pixel pitch	0.315 x 0.315 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	60 Hz
Vertical scan range	23 - 80 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	480p, 576p, 720p, 1080i, 1080p, 2160p
Contrast ratio (typical)	4000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	139.7 cm
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 900, 1920 x 1080 (HD 1080), 3840 x 2160
Certification	CEL, WEEE, ErP, TCO, BFR/PVC free
AC input voltage	100 - 240 V
Heat dissipation	307.8 BTU/h
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	200 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.4 W
Power consumption (typical)	100 W
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Package weight	27570 g
USB version	3.2 Gen 1 (3.1 Gen 1)
Ethernet LAN	Yes
Audio (L/R) in	2
USB connector type	USB Type-A
USB ports quantity	4
DVI-I ports quantity	0
Ethernet LAN (RJ-45) ports	1
Cables included	AC, DisplayPort, HDMI, USB, VGA
Orientation	Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	15.7 mm
Placement supported	Indoor
Bezel width (bottom)	25.55 mm
Panel mounting interface	400 x 400 mm
RMS rated power	20 W
Purpose	Corporate
Sustainability certificates	RoHS, ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	64.8 mm
Width	1241 mm
Height	721.5 mm
Weight	20500 g
