68 | Appendix
Pin assignments
RS232 Pin description RS232
1
2 TXD 2
3 RXD 3
4
5 GROUND 5
6
7 Not Used 7
8 Not Used 8
9
RS232 protocol communication settings
Connection settings Value
Baud Rate 9600 bps
Data Bits 8 bits
Parity None
Stop Bits 1 bit
Flow control None
