Dell D01T

Feature Specification
Tower 5810 one RJ-45
Serial one 9-pin connector
USB
Tower 5810
• front panel — three USB 2.0, and one USB 3.0
• back panel — three USB 2.0, and one USB 3.0
• internal — three USB 2.0
Video Video card dependent
• DVI connector
• mini DisplayPort
• DisplayPort
• DMS-59
Table 30. Internal Connectors
Feature Specification
System power one 28–pin connector
System fans three 4-pin connectors
Processor fans one 5-pin connector
HDD fans one 5-pin connector
Thunderbolt side band connector one 5-pin Connector
Memory eight 288–pin connectors
Processor one LGA-2011 socket
Back I/O:
PCI Express
PCI Express x4
Tower 5810 two 164-pin connectors
PCI Express x16
Tower 5810 two 164-pin connectors
PCI 2.3 one 124-pin connector
Front I/O:
Front USB one 14–pin connector
Internal USB one type A female, one dual-port 2x5 header
Front panel control one 2x14 pin connector
Front panel audio HDA header one 2x5 pin connector
Hard drive/ Optical drive:
SATA
Tower 5810
• four 7-pin SATA connectors for HDD
• two 7-pin SATA connectors for ODD
Power
Tower 5810 one 24-pin and one 10-pin connector
Technical Specifications 51
