9. optical-drive eject button (optional)
10. headphone connector
11. line-in/microphone connector
12. serial connector
13. USB 2.0 connectors
14. PS/2 Keyboard connector
15. USB 3.0 connectors
16. line-out connector
17. security cable slot
18. padlock ring
19. network connector
20. PS/2 Mouse connector
21. USB 3.0 connector
22. USB 2.0 connector
23. active expansion card slots
24. mechanical slot
25. power cable connector
26. power-supply unit (PSU) release latch
Figure 2. Inside View of T5810 Computer
1.
heatsink with integrated fan 2. memory shrouds
3. front bezel 4. optical drive bay (5.25”) and slimline optical drive bay
5. primary hard-drive slots (3.5” or 2.5”) 6. PSU-cable shroud
7. graphics card 8. intrusion switch
8 Removing and installing components
