Table 31. Controls and Lights
Feature Specification
Power button light: off — system is off or unplugged.
solid white light — computer is operating normally.
blinking white light — computer is in stand by.
solid amber light — the computer does not start, indicating a problem with the
system board or power supply.
blinking amber light — indicates a problem has occurred with the system board.
Drive activity light white light — blinking white light indicates that the computer is reading data
from, or writing data to the hard drive.
Network link integrity lights (back panel) green light — A good connection at 10 Mbs exists between the network and the
computer
orange light — A good connection at 100 Mbs exists between the network and
the computer.
yellow light — A good connection at 1000 Mbs exists between the network and
the computer.
Network activity lights (back panel) yellow light — flashes when there is network activity on the connection.
Table 32. Power
Feature Specification
Voltage 100 VAC to 240 VAC
Wattage
Tower 5810 685 / 425 W (input voltage of 100 VAC – 240 VAC)
Maximum heat dissipation
685 W 2750.5 BTU/Hr
425 W 1706.5 BTU/Hr
NOTE: Heat dissipation is calculated by using the power supply wattage rating.
Coin-cell battery 3 V CR2032 lithium coin cell
Table 33. Physical
Feature Specification
Tower 5810
Height (with feet) 416.90 mm (16.41 inches)
Height (without feet) 414.00 mm (16.30 inches)
Width 172.60 mm (6.79 inches)
Depth 471.00 mm (18.54 inches)
Weight (minimum): 13.50 kg (29.80 lb) / 12.40 kg (27.40 lb)
Table 34. Environmental
Feature Specification
Temperature:
Operating 10 °C to 35 °C (50 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative humidity (maximum) 20% to 80% (noncondensing)
52 Technical Specifications
