Dell D01T

5. Repeat Step 3 and Step 4 to remove the second memory shroud module from the computer.
Installing the Memory Shroud
1. Install the memory shroud module and press downwards until it clicks into place.
2. Install:
a) optical drive
b) computer cover
3. Follow the procedures in After Working Inside Your Computer.
Removing the Memory
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a) computer cover
b) optical drive
c) memory shroud
3. Press down on the memory-securing clips on each side of the memory module, and lift the memory module upwards to remove it from
the computer.
NOTE: Tilting of DIMM during removal can cause damage to the DIMM.
Installing the Memory
1. Insert the memory module into the memory socket.
2. Press down on the memory module until the securing clips secure the memory in place.
NOTE: Tilting of DIMM during insertion can cause damage to the DIMM.
3. Install:
a) memory shroud
b) optical drive
c) computer cover
22
Removing and installing components
