2. Follow the procedures in After Working Inside Your Computer.
Removing the Computer Cover
1. Follow the procedures in Before Working Inside Your Computer.
2. Lift up the cover-release latch.
3. Lift the cover upward to a 45–degree angle, and remove it from the computer.
Installing the Computer Cover
1. Place the computer cover on the chassis.
2. Press down on the computer cover until it clicks into place.
3. Follow the procedures in After Working Inside Your Computer.
Removing the PSU Card
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove:
a) computer cover
b) PSU
3. Perform the following steps as shown in the illustration:
10
Removing and installing components
