Removing and installing components
Recommended Tools
The procedures in this document may require the following tools:
• Small slotted-tip screwdriver
• #2 Phillips screwdriver
• #1 Phillips screwdriver
• Small plastic scribe
For how-to videos, documentation, and troubleshooting solutions, scan this QR code, or click here: http://www.Dell.com/QRL/
Workstation/T5810
System Overview
Figure 1. Front and Back View of T5810 Computer
1. microphone connector
2. power button/Power light
3. hard-drive activity light
4. USB 3.0 connector
5. USB 2.0 connectors
6. optical-drive (optional)
7. optical-drive eject button (optional)
8. optical-drive (optional)
2
Removing and installing components 7
