Page #64 background imageLoading...
Page #64 background image
Feature Specification
supports one 5.25–inches SATA optical device or supports
one 3.25–inches SATA HDD device
supports one media card reader
supports up to two 2.5–inches SAS/SATA/HDDs/SSDs
(with optional adapters)
Internally accessible
3.5–inch hard drive bays two:
supports two 3.25–inches SATA
supports 2.5–inches SAS/SATA/HDD/SSDs
Table 27. External Connectors
Feature Specification
Audio
front panel — mic-in, headphone-out
back panel — line-out, mic in/line In
Network
Tower 5810 one RJ-45
Serial one 9-pin connector
USB
Tower 5810
front panel — three USB 2.0, and one USB 3.0
back panel — three USB 2.0, and one USB 3.0
internal — three USB 2.0
Video Video card dependent
DVI connector
mini DisplayPort
DisplayPort
DMS-59
Table 28. Internal Connectors
Feature Specification
System power one 28–pin connector
System fans three 4-pin connectors
Processor fans one 5-pin connector
HDD fans one 5-pin connector
Thunderbolt side band connector one 5-pin Connector
Memory eight 288–pin connectors
Processor one LGA-2011 socket
Back I/O:
PCI Express
64
