Table 23. Diagnostic Indicator table (continued)
Power Light: Amber-White
Blinking
Amber/White Blinking
Pattern
Problem Description Suggested Resolution
the issue by removing one
by one the memory on
motherboard to determine
which one failed.
• Contact Tech Support.
2-6 2 amber blinks followed by a
short pause, 6 white blinks, long
pause, then repeats
Motherboard: Chipset
• Fatal system board failure
detected.
• If customer can assist to
troubleshoot, narrow down
the issue by removing one
by one the component on
motherboard to determine
which one failed.
• If you identified any of the
components failed, replace
the Component.
• Contact Tech Support.
3-2 3 amber blinks followed by a
short pause, 2 white blinks, long
pause, then repeats
PCI Device or Video
• PCI device configuration
activity is in progress or PCI
device failure was detected.
• If you can assist to
troubleshoot, narrow down
the issue by reseating PCI
card and removing one by
one to determine which card
failed.
• Contact Tech Support.
3-3 3 amber blinks followed by a
short pause, 3 white blinks, long
pause, then repeats
BIOS Recovery 1
• System is in Recovery
Mode.
• Flash latest BIOS version. If
problem persists, contact
Tech Support
3-4 3 amber blinks followed by a
short pause, 4 white blinks, long
pause, then repeats
BIOS Recovery 2
• System is in Recovery
Mode.
• Flash latest BIOS version. If
problem persists, contact
Tech Support
4-6 4 amber blinks followed by a
short pause, 6 white blinks, long
pause, then repeats
RAID Volume degraded
• RAID volume is degraded.
• If you can assist to
troubleshoot, us F12 menu
to enter Device
Configuration tab. Rebuild
the RAID volume if possible
• Contact Tech Support.
4-7 4 amber blinks followed by a
short pause, 7 white blinks, long
pause, then repeats
System Side cover is missing
• System side cover(either
left or right) is missing.
• Unplug power, Install back all
side covers back to the
chassis and plug in power.
• Contact Tech Support.
Troubleshooting 129
