28 │ Setting Up the Monitor
Connecting Your Monitor
WARNING: Before you begin any of the procedures in this section, follow the
"Safety Instructions".
NOTE: Do not connect all cables to the computer at the same time.
NOTE: Dell monitors are designed to work optimally with Dell supplied inbox
cables. Dell does not guarantee the video quality and performance when using
non-Dell cables.
NOTE: The graphics are used for the purpose of illustration only. Appearance on
the computer may vary.
To connect your monitor to the computer:
1. Turn off your computer and disconnect the power cable.
2. Connect the black VGA or HDMI or DP cable to the corresponding video port on the
back of your computer.
3. Connect the Earphone port.(D2421H)
Connecting VGA/HDMI Cable and Earphone
D2421H
HDMI
VGA
Connecting VGA/HDMI Cable
D2721H
