Replacing a storage processor
T
his procedure describes how to replace a storage processor.
Steps
1. Slide the storage processor into the chassis as far as it will go (1).
2. R
otate the storage processor extraction levers upwards until the storage processor retracts fully into place and the storage
processor extractors snap into place (2).
NOTE:
The extractors snapping into place is not guaranteed. Press the release buttons, and then swing the extractors
into place. Then, let go the release buttons. If testing when the SP is fully seated, attempt to swing out the extractors
without releasing them.
40 Field Replaceable Units
