Dell E1909W - Page 40

Service Manual
39
320
412000241550R
A
IC AME1117CCCTZ 3.3V,TO-252
(AM E)RoHS
AME,
0
320
412000332020R
A
IC LD1117AL-3.3-A TO-252(UTC)RoHS
UTC,
0
320
412000332830R
A
IC AS1117R-3.3.TR-LF,TO-252(A1 SEMI)
RoHS
A1SEMI,
0
330
412000330020R
A
IC LD1117AL-1.8V-A SOT223(UTC) RoHS
UTC,
1
U102,
330
412000330830R
A
IC AS1117L-1.8/TR-LF,SOT223(A1 SEMI)
RoHS
A1SEMI,
0
330
412000330070R
A
IC AZ1117H-1.8 SOT223(AAC)RoHS
BCD,
0
340
412000435481R
A
IC AT24C02BN-SH-T 2K SOIC8(ATMEL
)RoHS
ATMEL,
2
U103,U201,
340
412000480280R
A
IC M24C02-RMN6TP SO8(ST)RoHS
ST,
0
340
412000480990R
A
IC CAT24C02WI-TE13
SOIC-8(CATALYST)RoHS
CATALYST,
0
350
412000652060R
IC TSUM5PEHJ-LF-2 PQFP128(MSTAR
)Rohs
MSTAR,
1
U105,
360
412000224482R
A
IC AT24C16BN-SH-T 16K(ATMEL) SOIC 8
ROHS
ATMEL,
1
U106,
360
412000224280R
A
IC M24C16-WMN6TP SO8 16K (ST) ROHS
ST,
0
360
412000481990R
A
IC CAT24C16WI-TE13
SOIC-8(CATALYST)RoHS
CATALYST,
0
370
412000494190R
A
IC SST25LF020A-33-4C-SAE SOIC8(SST
)ROHS
SST,
1
U108,
370
412000661620R
A
IC MX25L2025MC-12G (MXIC)RoH
MXIC,
0
370
412000494310R
A
IC PM25LV020-100SCE SOIC8(PMC)
RoHS
PMC,
0
380
411130962950R
A
ZENER 6.2V MMSZ5234B
SOD-123(PANJIT)RoH
PANJIT,
9
ZD102,ZD103,ZD104,ZD105,ZD106,ZD201
,ZD203,ZD204,ZD107,
380
411121462950R
A
ZENER 6.2V BZT52-C6V2
SOD-123(WILLAS)ROH
WILLAS,
0
380
411131562950R
A
ZENER 6.2V BZT52C6V2-7-F
SOD-123(DIODES)
DIODES,
0
390
491351300100R
A
PCB,I/F BOARD,LE19E6 ROHS
EXPRESS,GOODWELL
,WELFARE,
1
2. power board BOM
ITEM
P/N
Description
Supplier
Usage
Un
Location
791711400800R
PCBA,P/I BOARD W/O SPK,LE19E6-812 ROHS
10
430637020030R
WFR. 2P P=3.5mm 90°W/LOCK,RoHS
CVILUX,FCN,FOXCONN,
4
PC
CN1,CN2,CN3,CN4,
20
440149000400R
SKT AC 10A/250V U/C/V,CDJ-3(E4 )-BT3.6-0
TECX,
1
PC
CN850,
30
430300801650R
HRN ASS'Y 8P 130mm UL1007 24 AWG ROHS
FOXCONN,HEIGHTEN,JVE,
1
PC
CN853,
40
420424710510R
CAP SD 470uF/50V M 105 F 13x21 RoHS
LELON,SAMXON,SU'SCON,TEAPO,
2
PC
C20,C863,
50
418103051920R
CAP CD NPO 3pF 3KV D,S7.5, RoHS
JNC,SUCCESS(SEC),
4
PC
C21,C22,C23,C24,
50
418103058920R
CAP CD SL 3pF 3KV D,S7.5,RoHS
JNC,SUCCESS(SEC),
0
PC
60
418105051920R
CAP CD NPO 5pF 3KV D,S7.5, RoHS
JNC,SUCCESS(SEC),
2
PC
C25,C27,
70
416202223620R
CAP MEY 2200pF 250V M Y2 Y5V,W /O FORMIN
JNC,POE,SUCCESS(SEC),
2
PC
C850,C851,
80
416194743011R
CAP MEX 0.47uF 275V K X2,F15 RoHS
ARCOTRONIC,EUROPTRONIC,HJC,SCC,
1
PC
C852,
90
420431014083R
CAP SEK 100uF/450V M,105 CF,18x40(2.5)
ELITE,SAMXON,SU'SCON,
1
PC
C854,
100
416213323620R
CAP MEY 3300pF 250V M Y1,F10mm W/O FORMI
JNC,POE,SUCCESS(SEC),
1
PC
C860,
110
416304723510R
CAP PP 0.0047uF 250V J,F7.5 RoHS
EUROPTRONIC,HJC,SCC,
1
PC
C875,
120
415502438551R
RES NKNP 2W 0.43Ω J, MINI,HK15,ROHS
FUTABA,QUEENMAO,TZAI YUAN,
1
PC
R859,
130
415350511550R
RES MOF 2W 510Ω J,MINI HK15,ROHS
FUTABA,QUEENMAO,TZAI YUAN,
1
PC
R888,
140
432009400701R
NTC 5Ω 4A 10ψ P=5mm, F RoHS
THINKING,UPPERMOST,
1
PC
RT850,
150
426000050070R
CHOKE L-FILTER 12mH LIN-007 ET-20,RoHS
DARFON,FOXCONN,LISHIN,MEIKAI,NCE,
1
PC
L850,
160
425000010530R
COIL CHK 5uH 7.8X10 CHK-053 0 181085R0L
CHILISIN,EASYMAGNET,FOXCONN,FRONTIER,
1
PC
L854,
170
411050012010R
DIO BRDG GBU405 600V/4A(TSC)RoHS
TSC,
1
PC
D850,
170
411050012020R
DIO BRDG GBU4-06-BF52 600V/4A(FEC)RoHS
FRONTIER,
0
PC
180
411030068020R
DIO SF50-04F69-LF 400V/5A DO-201AD(FEC)R
FRONTIER,
1
PC
D854,
180
411030068450R
DIO SF55PT-F 400V/5A DO-201AD(CHENMKO)RO
CHENMKO,
0
PC
180
411030071450R
DIO SF56PT-F 600V/5A DO-201AD(CHENMKO)RO
CHENMKO,
0
PC
180
411030068520R
DIO SF50GG-E1 400V/5A DO-201AD(LITEON)R
LITEON,
0
PC
190
411090050090R
SCHTKY SB5150F98 150V/5A DO-201AD (PANJI
PANJIT,
2
PC
D856,D857,
190
411090050020R
SCHTKY SR515F69-LF 150V/5A DO-201AD (FEC
FRONTIER,
0
PC
