Dell E1909W - Page 41

Service Manual
40
190
411090050450R
SCHTKY SR5150PT-F 150V/5A DO-201AD (CHEN
CHENMKO,
0
PC
200
426000091160R
XFMR SW DIP EEL22 P4 800uH SPW-116 ROHS
DARFON,FOXCONN,HUALON,LISHIN,
1
PC
T1,
210
426000091150R
XFMR SW DIP ER28 TP4 550uH SPW-115 ROHS
FOXCONN,FRONTIER,LISHIN,MEIKAI,
1
PC
T850,
220
412140002380R
IC LTV817M-PR VDE (LITE-ON) P=10mm RoHS
LITEON,
1
PC
I850,
240
735110007800R
ASSY,H/S,Q850, LE19E6-812,ROHS
1
PC
250
791711440800R
PCBA,P/I BOARD W/O SPK,SMT LE19E6-812 RO
1
PC
260
415350100550R
RES MOF 2W 10Ω J,MINI,HK15, RoHS
FUTABA,QUEENMAO,TZAI YUAN,
2
PC
R861,R863,
2E+07
ITEM
P/N
Description
Supplier
Usage
Un
Location
735110007800R
ASSY,H/S,Q850, LE19E6-812,ROHS
10
410050103050R
XSTR FMA09N65GX N-CH TO-220F(FUJI) RoHS
FUJI,
1
PC
Q850,
10
410500059290R
XSTR AP2761I-A N-CH TO-220CFM ADVANCED P
APEC,
0
PC
10
410050057280R
XSTR STP8NK80ZFP N-CH TO220FP (ST)
ST,
0
PC
30
507300003300R
HEATSINK,"L", LE1713/1913
DMC,ORIENTAL POWER,
1
PC
40
509146306200R
SCREW,P,CROSS,W/WAS,M3*6,Zn-Cc
GAOYI,LIQUAN,YIJIE,
1
PC
2E+07
ITEM
P/N
Description
Supplier
Usage
Un
Location
791711440800R
PCBA,P/I BOARD W/O SPK,SMT LE19E6-812 RO
10
419312720070R
C SMD (0805) X7R 2700pF 50V K ROHS
DARFON,TDK,WALSIN,YAGEO,
4
PC
C1,C15,C16,C17,
20
419311054070R
C SMD(0805) X7R 1uF/16V K RoHS REV:A
DARFON,TDK,WALSIN,YAGEO,
1
PC
C2,
30
419311020070R
C SMD(0805) X7R 1000PF/50V K RoHS
DARFON,TDK,WALSIN,YAGEO,
4
PC
C4,C5,C847,C848,
40
419312233070R
C SMD(0805) X7R 0.022uF/25V K RoHS
DARFON,TDK,WALSIN,YAGEO,
2
PC
C6,C14,
50
419314730070R
C SMD(0805) X7R 0.047uF/50V K ROHS
DARFON,TDK,WALSIN,YAGEO,
3
PC
C12,C13,C7,
60
419312210070R
C SMD(0805) X7R 220PF/50V K RoHS
DARFON,TDK,WALSIN,YAGEO,
1
PC
C8,
70
419311040070R
C SMD(0805) X7R 0.1uF/50V K RoHS REV:A
DARFON,TDK,WALSIN,YAGEO,
5
PC
C9,C10,C871,C876,C26,
80
419311030070R
C SMD(0805) X7R 0.01uF/50V K RoHS
DARFON,TDK,WALSIN,YAGEO,
3
PC
C11,C849,C859,
90
414908510110R
RES SMD (0805) 5.1KΩ F,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
4
PC
R1,R2,R11,R858,
100
414908027350R
RES SMD (0805) 27KΩ J,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
4
PC
R3,R4,R14,R15,
110
414908390010R
RES SMD (0805) 390Ω F,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
2
PC
R6,R19,
120
414908100310R
RES SMD (0805) 100KΩ F,RT,RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
3
PC
R5,R22,R848,
130
414908953210R
RES SMD (0805) 95.3KΩ F,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
1
PC
R16,
140
414908510210R
RES SMD (0805) 51KΩ F,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
2
PC
R8,R18,
150
414908010550R
RES SMD (0805) 1MΩ J,RT RoHS REV:A
TA-I,UNIOHM,WALSIN,YAGEO,
2
PC
R9,R10,
160
414908100210R
RES SMD (0805) 10KΩ F,RT RoHS REV:A
TA-I,UNIOHM,WALSIN,YAGEO,
8
PC
R12,R13,R21,R23,R860,R884,R886,R887,
170
414908330310R
RES SMD (0805) 330KΩ F,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
1
PC
R17,
180
414908100110R
RES SMD (0805) 1KΩ F,RT RoHS REV:A
TA-I,UNIOHM,WALSIN,YAGEO,
4
PC
R20,R24,R30,R31,
190
414908047050R
RES SMD (0805) 47Ω J,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
2
PC
R840,R844,
200
414904499310R
RES SMD (1206) 499KΩ F,RT RoHS REV:A
TA-I,UNIOHM,WALSIN,YAGEO,
6
PC
R841,R842,R843,R850,R851,R852,
210
414904270210R
RES SMD (1206) 27kΩ F,RT ROHS
TA-I,UNIOHM,WALSIN,YAGEO,
3
PC
R853,R854,R855,
220
414908100910R
RES SMD(0805)10Ω F,RT ROHS
TA-I,UNIOHM,WALSIN,YAGEO,
1
PC
R856,
230
414908270010R
RES SMD (0805) 270Ω F,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
1
PC
R857,
240
414908330110R
RES SMD (0805) 3.3KΩ F,RT RoHS REV:A
TA-I,UNIOHM,WALSIN,YAGEO,
1
PC
R868,
250
414908390110R
RES SMD (0805) 3.9KΩ F,RT RoHS
TA-I,UNIOHM,WALSIN,YAGEO,
1
PC
R872,
270
411023004021R
DIO SN4148-LF 75V/0.15A SMD 1206 (FEC)Ro
FRONTIER,
1
PC
D841,
270
411020046090R
DIO 1N4148W 75V/0.15A(PEC)RoHS SOD-123
PANJIT,
0
PC
270
411020046310R
DIO 1N4148W-F 75V/0.15A(DIODES RoHS,SOD-
DIODES,
0
PC
280
411020068020R
DIO BAW56 70V SOT-23(FRONTIER)RoHS
FRONTIER,
1
PC
ZD1,
280
411020068090R
DIO BAW56 75V SOT-23(PANJIT)RoHS
PANJIT,
0
PC
280
411020068210R
DIO BAW56 85V SOT-23(PHILIPS)RoHS
PHILIPS,
0
PC
290
411020047410R
DIO BAV70 70V SOT23(MITSUBISHI RoHS
MITSUBISHI,
2
PC
ZD2,ZD3,
290
411020047210R
DIO BAV70 85V SOT23 (PHILIPS) RoHS
PHILIPS,
0
PC
290
411020047090R
DIO BAV70, 70V SOT-23(PEC) ROHS
PANJIT,
0
PC
290
411020047020R
DIO BAV70-LF, 70V SOT-23(FEC) ROHS
FRONTIER,
0
PC
300
411131556950R
ZENER 5.6V 0.5W BZT52C5V6-F,SO D123(DIOD
DIODES,
2
PC
ZD4,ZD5,
300
411121456950R
ZENER 5.6V BZT52-C5V6 SOD-123(WILLAS)ROH
WILLAS,
0
PC
300
411131056050R
ZENER 5.6V 0.5W BZX79-C5V6 DO3 5(PHILIPS
PHILIPS,
0
PC
300
411120956950R
ZENER 5.6V 0.41W BZT52-C5V6,SO D123(PANJ
PANJIT,
0
PC
310
411020026210R
DIO BAV99 350mW 70V SOT-23(PHI RoHS
PHILIPS,
2
PC
ZD6,ZD7,
310
411020026390R
DIO BAV99,SOT-23(INFINEON)RoHS
INFINEON,
0
PC
310
411020026090R
DIO BAV99 350mW 75V SOT-23(PEC RoHS
PANJIT,
0
PC
310
411020026020R
DIO BAV99-LF 350mW 70V SOT-23 (FEC)RoHS
FRONTIER,
0
PC
