Dell E1909W - Page 42

Service Manual
41
320
410080003290R
XSTR AP4575GM N&P SO-8(APEC)ROHS
AP,
2
PC
Q6,Q7,
320
410080003430R
XSTR P5506NVG N&P SOP-8(NIKO-SEM)ROHS
NIKO,
0
PC
330
410070010240R
XSTR MMBT4401 NPN SOT23(FAIRCHILD)RoHS
FAIRCHILD,
1
PC
Q851,
330
410070010420R
XSTR MMBT4401 NPN SOT23(PANJIT)RoHS
PANJIT,
0
PC
330
410070010210R
XSTR PMBT4401 NPN SOT23(PHILIPS)RoHS
PHILIPS,
0
PC
340
412000628810R
IC LD7552BPS SOP8（Leadtrend)ROHS
LEADTREND,
1
PC
U850,
350
412000654630R
IC INL833GN SOP16(O2 MICRO)Rohs
O2,
1
PC
U1,
360
791711410800R
PCBA,P/I BOARD W/O SPK,AI LE19E6-812 ROH
1
PC
370
419312254070R
C SMD(0805) X7R 2.2uF 16V K RoHS
DARFON,MURATA,TDK,WALSIN,YAGEO,
1
PC
C3,
2E+07
ITEM
P/N
Description
Supplier
Usage
Un
Location
791711410800R
PCBA,P/I BOARD W/O SPK,AI LE19E6-812 ROH
10
791711450800R
PCBA,P/I BOARD W/O SPK,AI/A LE19E6-812 R
1
PC
20
791711460800R
PCBA,P/I BOARD W/O SPK,AI/R LE19E6-812 R
1
PC
2E+07
ITEM
P/N
Description
Supplier
Usage
Un
Location
791711450800R
PCBA,P/I BOARD W/O SPK,AI/A LE19E6-812 R
10
411032006020R
DIO FR10-10-LF 1000V/1A AT(FRO NTIER)RoH
FRONTIER,
1
PC
D851,
10
411032006040R
DIO FR107 1000V/1A DO-41(MOSPE C)RoHS
MOSPEC,
0
PC
10
411020053090R
DIO PS1010R 1000V/1A DO-41(PAN JIT)RoHS
PANJIT,
0
PC
20
411020064090R
DIO ER104 400V/1A DO-41(PANJIT RoHS
PANJIT,
1
PC
D852,
20
411032001020R
DIO SF10-04-LF 400V/1A DO-41(F RONTIER)R
FRONTIER,
0
PC
30
415211009140R
RES MF 1/8W 10Ω F,AT,RoHS
QUEENMAO,TZAI YUAN,UNIOHM,
1
PC
R7,
40
415212703140R
RES MF 1/8W 270KΩ F,AT,RoHS
QUEENMAO,TZAI YUAN,UNIOHM,
1
PC
R871,
50
411131430010R
ZENER 30V GDZ30A DO35(WILLAS)RoHS
WILLAS,
1
PC
ZD880,
50
411130930010R
ZENER 30V GDZ30A DO35(PANJIT)RoHS
PANJIT,
0
PC
60
430613050100R
FUSE SLOW PICO II 5A/125V U/C,AT,ROHS
LITTELFUSE,
1
PC
F851,
60
430613050101R
FUSE SLOW 5A/125V U/C,AT,ROHS
WALTER,
0
PC
70
491531400800R
PCB,P/I ,1/OSP /CEM1/16,LE19E6-812 ROHS
HSIANGKUO,TATCHUN,
1
PC
80
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 7.5MM
HOTRON,YUANYE,
550
MM
J3,J5,J6,J7,J8,J10,J12,J9,J18,J15,J20,
80
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 7.5MM
HOTRON,YUANYE,
0
MM
90
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 10MM
HOTRON,YUANYE,
100
MM
J4,J13,
90
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 10MM
HOTRON,YUANYE,
0
MM
100
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 15MM
HOTRON,YUANYE,
100
MM
J1,J2,
100
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 15MM
HOTRON,YUANYE,
0
MM
110
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 12.5MM
HOTRON,YUANYE,
200
MM
J11,J16,J17,J19,
110
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 12.5MM
HOTRON,YUANYE,
0
MM
120
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 17.5MM
HOTRON,YUANYE,
50
MM
J14,
120
430405000000R
JMPR ROLL/KG D=0.6mm,AT,RoHS 17.5MM
HOTRON,YUANYE,
0
MM
2E+07
ITEM
P/N
Description
Supplier
Usage
Un
Location
791711460800R
PCBA,P/I BOARD W/O SPK,AI/R LE19E6-812 R
20
420421000530R
CAP SD 10uF/50V M,VT 105 5x11 RoHS
LELON,SAMXON,SU'SCON,TEAPO,
1
PC
C855,
30
420424710231R
CAP SD 470uF/25V M 105 VT 10x16 RoHS
LELON,SAMXON,SU'SCON,TEAPO,
3
PC
C856,C857,C858,
50
412022002240R
IC KA431AZ 1%,VT (FAIRCHILD) RoHS
FAIRCHILD,
1
PC
I851,
50
412022002550R
IC AME431BAJATB25Z TO-92-3(AME RoHS
AME,
0
PC
50
412022002830R
IC AS431 TO-92 VT(A1SEMI)RoHS
A1SEMI,
0
PC
50
412022002840R
IC TL431ACLPG TO-92 1%,VT(ON)RoHS
ON SEMI,
0
PC
50
412022002440R
IC AZ431BZ-ATRE1 TO-92(BCD) RoHS
BCD,
0
PC
60
430613830290R
FUSE TIME LAG 3.15A/250V,RoHS
BELFUSE,CONQUER,LITTELFUSE,WALTER,
1
PC
F850,
70
418210233030R
CAP CD X7R 1000pF/1KV K,VT 2X7R102K102K5
JNC,POE,SUCCESS(SEC),
2
PC
C862,C873,
3.PCBA KEYPAD BOM
ITEM
P/N
Revision
Description
Supplier
Usage
Location
791711500000R
PCBA,KEYPAD BOARD,LE19E6 ROHS
10
430602680160R
SW,METAL DOME 180gf 5P ROHS
FOXCONN ,HUA-JIE,
1
20
430631080190R
WFR 8P 1.25MM 180° W/LOCK ROHS
JOWLE,FOXCONN
1
CN101,
