7. Inner Connector Pin Assignment
7.1 CN501 (Connect M/B to Panel, C11330MGHR0 or compatible connector)
Pin Symbol Description
1 Panel_Vcc Panel power supply (typ.5.0V)
2 Panel_Vcc Panel power supply (typ. 5.0V)
3 Panel_Vcc Panel power supply (typ. 5.0V)
4 NC
5 NC
6 NC
7 GND_LVDS LVDS Ground
8 RXE3+ LVDS signal of even channel 3(-)
9 RXE3- LVDS signal of even channel 3(+)
10 RXEC+ LVDS signal of even channel clock (+)
11 RXEC- LVDS signal of even channel clock (-)
12 RXE2+ LVDS signal of even channel 2(+)
13 RXE2- LVDS signal of even channel 2(-)
14 GND_LVDS LVDS Ground
15 RXE1+ LVDS signal of even channel 1(+)
16 RXE1- LVDS signal of even channel 1(-)
17 GND_LVDS LVDS Ground
18 RXE0+ LVDS signal of odd channel 0(+)
19 RXE0- LVDS signal of odd channel 0(-)
20 RXO3+ LVDS signal of odd channel 3(+)
21 RXO3- LVDS signal of odd channel 3(-)
22 RXOC+ LVDS signal of even channel clock (+)
23 RXOC- LVDS signal of even channel clock (-)
24 GND_LVDS LVDS Ground
25 RXO2+ LVDS signal of even channel 2(+)
26 RXO2- LVDS signal of even channel 2(-)
27 RXO1+ LVDS signal of even channel 1(+)
28 RXO1- LVDS signal of even channel 1(-)
29 RXO0+ LVDS signal of odd channel 0(+)
30 RXO0- LVDS signal of odd channel 0(-)
7.2 CN1, CN2 (Connect to Panel Backlight, SM02B-BHSS-1-TB or compatible connector)
Pin Symbol Description
1 HV High voltage for lamp
2 LV Low voltage for lamp
7.3 CN401 (Connect to keypad, SZ7103016B or compatible connector)
Pin Symbol Description
1 MENU OSD “MENU” control
2 DOWN OSD “-” control
3 UP OSD “+” control and auto adjustment control
4 GND Ground
5 GND Ground
6 LED_Green LED Green on/off control
7 LED_Amber LED amber on/off control
8 Power Power on/off control
