Dell E190Sf User Manual

Service Manual
34
410050114290R XSTR AP2764AI-A N-CH 650V/9A TO-220CFM APEC,
410050103050R XSTR FMA09N65GX N-CH TO-220F(FUJI) RoHS FUJI,
410050057280R XSTR STP8NK80ZFP N-CH TO220FP (ST) ST,
Switch
MOS
Q850
492421400100H PCB,PCB,P/I ,1/OSP /CEM1/16,LE19S1,HF
HUIHO,
TATCHUN,
PCB
492422200000H PCB,CRL-I ,2/OSP /FR4/12(INL816)LE19S1,H
EXPRESS,
SHENG HUA PCB
490712100200H PCB,CONTROL(PWR LD7575),LE1521 EXPRESS PCB
ATTACHMENT 1- Bill of Material
MNT BOM
E190Sf MNT BOM
Lv Item Component no. Object description Quantity BUn RevLev
1 10 453070800150R PWR CORD 10A/125V BLK 6FT UL/CSA SVT 3Cx 1 PC C
1 20 453010100320R CABLE D-SUB 15P MALE 6FT BLACK/BLUE AB 8 1 PC B
1 30 714070HA2000R ASSY,FINAL(B)W/O SPK,LE19S1-A10(E190Sf) 1 PC A
1 40 713100016000R ASSY, PACKAGE, PACK, DAO,LE19S1 1 PC A
1 714070HA2000R ASSY,FINAL(B)W/O SPK,LE19S1-A10(E190Sf)
2 10 509012202100R SCREW,I,CROSS,T.T-2*2.5,Zn,ROHS 2 PC A
2 20 509116610510R SCREW,P,CROSS,M4*10,BLACK-NL(NYLOK) 4 PC A
2 30 503020004409R RUBBER,FOOT,10x20x3.8mm 2 PC A
2 40 714050024200R ASS'Y BACK COVER LE19S1 1 PC A
2 50 714000001410R ASSY,RELEASE BUTTON(B), LE1X28 1 PC A
2 60 714020021000R ASS'Y STAND LE19S1 1 PC A
2 70 714030027001R ASS'Y FRONT BEZEL ,LE19S1 1 PC A
2 80 714080HA2000R ASSY,PANEL,W/O SPK,LE19S1-A10(E190Sf) 1 PC A
1 713100016000R ASSY, PACKAGE, PACK, DAO,LE19S1
2 10 506140005800R LABEL BARCODE LE1963 1 PC B
2 20 506250001900R LABEL,AGENCY,LE19S1 1 PC A
2 30 506431011200R FILM,SCREEN,PROTECTION,PRINTED,LE19S1 1 PC A
2 40 506380001400R TAPE 3M-897 12x45000mm 0.00333 PC A
2 50 506280011401R POSTER,QUICK SETUP,WEST, LE19S1 1 PC A
2 60 703500013600R KIT,ACCESSORY, DOC, DAO, LE19S1 1 PC A
2 70 506120300060R BAG, PLASTIC,L670*W440mm(PRINTED), LE22E 1 PC A
2 80 506120004400R BAG PLASTIC L540xW460xT0.05mm(PRINTED)LE 1 PC B
2 90 506020003700R CARTON,DELL(WWW), LE19S1 1 PC A
2 100 506060017600R CUSHION TOP,LE19S1 1 PC A
2 110 506060017601R CUSHION BUTTOM ,LE19S1 1 PC A
2 120 506340004700R LABEL BLANK 101X50mm DELL EMEA CARTON 1 PC A
2 130 506380002622R TAPE, WRAPPING TYPE PRINTED(DELL), BLACK 0.00134 ROL A
2 140 713000100500R ASSY PACK,20STD,LE19S1 PC A
2 140 713000100501R ASSY PACK,40STD,LE19S1 1 PC A
2 140 713000100502R ASSY PACK,40HQ,LE19S1 PC A
2 140 713000100506R ASSY PACK,AIR CARGO (20STD),LE19S1 PC A
