Dell E190Sf - Page 42

Service Manual
41
10 419311044010R C SMD(0402) X7R 0.1uF/16V,K,RoHS TDK,WALSIN,YAGEO, 30
C505,C503,C502,C435,
C431,C430,C429,C428,
C426,C424,C423,C418,
C411,C410,C409,C408,
C407,C405,C404,C310,
C312,C601,C605,C604,
C606,C434,C440,C441,
C443,C444,
20 419302700510R C SMD(0402) NPO 27PF/50V J RoHS
MURATA,TDK,WALSIN,YAGE
O,
2 C307,C308,
30 419301010510R C SMD(0402) NPO 100PF/50V J,RoHS
MURATA,TDK,WALSIN,YAGE
O,
2 C311,C309,
40 419301000510R C SMD(0402) NPO 10PF/50V J,RoHS
MURATA,TDK,WALSIN,YAGE
O,
2 C413,C414,
50 411020026210R DIO BAV99 350mW 70V SOT-23(PHI RoHS PHILIPS, 3 D301,D302,D303,
50 411020026090R DIO BAV99 350mW 75V SOT-23(PEC RoHS PANJIT, 0
50 411020026020R
DIO BAV99-LF 350mW 70V SOT-23
(FEC)RoHS
FRONTIER, 0
60 411020047210R DIO BAV70 85V SOT23 (PHILIPS) RoHS PHILIPS, 1 D306,
60 411020047020R DIO BAV70-LF, 70V SOT-23(FEC) ROHS FRONTIER, 0
70 432002319041R
BEAD CORE SMD(0603)19Ω 500mA,
SBK160808
CHILISIN,TAI-TECH, 6
L301,L302,L303,L401,L
402,L405,
80 432002312144R
BEAD CORE SMD(0603)120Ω 300mA
SBK160808
CHILISIN,TAI-TECH, 2 L410,L407,
90 432002360111R
BEAD CORE SMD(0805) 600Ω 2A
PBY201209T-
CHILISIN,MAGLAYERS,TAI-T
ECH,
3 L414,L412,L601,
100 432002330140R BEAD CORE SMD(0603)300Ω 200mA RoHS
CHILISIN,MAGLAYERS,TAI-T
ECH,
5
L413,L411,L403,L404,L
406,
110 410500045440R
XSTR LMBT3904LT1G NPN 200mA 40V
SOT23(
LRC, 1 Q502,
110 410500045210R
XSTR PMBT3904 NPN 200MA,40V
SOT23(PHILIP
PHILIPS, 0
110 410500045140R
XSTR MMBT3904LT1G NPN 200MA 40V
SOT23(ON
ON SEMI, 0
120 410060007270R XSTR AO3419 P-CH,SOT23(AOS)RoHS AOS, 1 Q501,
120 410060011390R
XSTR ASM2307M/TR-LF P-CH
SOT-23(A1SEMI)R
A1SEMI, 0
120 410500068290R XSTR AP2305GN P-CH SOT23(APEC) RoHS APEC, 0
130 414918047250R RES SMD (0402) 4.7KΩ J,RT,RoHS
TA-I,UNIOHM,WALSIN,YAGE
O,
11
R430,R413,R412,R411,
R410,R409,R408,R314,
R313,R312,R501,
140 414918010250R RES SMD (0402) 1KΩ J,RT,RoHS
TA-I,UNIOHM,WALSIN,YAGE
O,
4 R428,R427,R426,R425,
150 414918750910R RES SMD (0402) 75Ω F,RT,RoHS
TA-I,UNIOHM,WALSIN,YAGE
O,
3 R306,R305,R304,
160 414918560910R RES SMD (0402) 56Ω F,RT,RoHS
TA-I,UNIOHM,WALSIN,YAGE
O,
5
R316,R315,R303,R302,
R301,
170 414918010150R RES SMD (0402) 100Ω J,RT,RoHS
TA-I,UNIOHM,WALSIN,YAGE
O,
10
R404,R405,R319,R318,
R317,R311,R310,R309,
R308,R307,
