Port I
Sets the drive type of the selected device. For Embedded SATA settings in ATA mode, set
this field to Auto to enable BIOS support. Set it to OFF to turn off BIOS support.
For AHCI or RAID mode, BIOS support is always enabled.
Option
Description
Model
Specifies the drive model of the selected device.
Drive Type
Specifies the type of drive attached to the SATA port.
Capacity
Specifies the total capacity of the hard drive. This field is undefined for removable media
devices such as optical drives.
Port J
Sets the drive type of the selected device. For Embedded SATA settings in ATA mode, set
this field to Auto to enable BIOS support. Set it to OFF to turn off BIOS support.
For AHCI or RAID mode, BIOS support is always enabled.
Option
Description
Model
Specifies the drive model of the selected device.
Drive Type
Specifies the type of drive attached to the SATA port.
Capacity
Specifies the total capacity of the hard drive. This field is undefined for removable media
devices such as optical drives.
Integrated Devices
You can use the Integrated Devices screen to view and configure the settings of all integrated
devices including the video controller, integrated RAID controller, and the USB ports.
Viewing Integrated Devices
To view the Integrated Devices screen, perform the following steps:
Procedure
1. Turn on, or restart your system.
2. Press F2 immediately after you see the following message:
F2 = System Setup
Note:
If your operating system begins to load before you press F2, wait for the system
to finish booting, and then restart your system and try again.
3. On the System Setup Main Menu screen, click System BIOS.
Pre-operating system management applications
