Figure 28. Installing a drive into the drive carrier
Related link
Removing a drive blank
Installing the front bezel
Removing a 2.5 inch drive from a 3.5 inch drive adapter
Prerequisites
1 Follow the safety guidelines listed in Safety instructions.
2 Remove the 3.5 inch drive adapter from the 3.5 inch drive carrier.
NOTE
: A 2.5 inch drive is installed in a 3.5 inch drive adapter, which is then installed in the 3.5 inch drive carrier.
Steps
1 Using the Phillips #2 screwdriver, remove the screws from the side of the 3.5 inch drive adapter.
2 Remove the 2.5 inch drive from the 3.5 inch drive adapter.
