General specifications
– LTE: 700 (B17/B12/B13)/850 (B5)/AWS1700 (B4)/1900 (B2)
– UMTS/HSPA: 850, 1900 MHz
• DW5812 supported frequencies
– LTE: 700 (B13)/AWS1700 (B4)/1900 (B2)
• LTE FDD Cat.4, 3GPP release 9 compliant
• Rx diversity and MIMO DL 2x2
• SIM application Tool Kit 3GPP TS 51.014
• Serial port multiplexer 3GPP TS27.010
• SMS over IMS
• Built-in UDP/TCP/FTP/SMTP stack
• Control through AT commands according to 3GPP TS 27.005, 27.007 and Telit Custom AT commands
Data specifications
• LTE Cat.4
• Uplink up to 50 Mbps
• Downlink up to 150 Mbps DC-HSPA+ 42 Mbps (supported on the variants with 3G fallback)
Electrical specifications
• Output power: Class 3 (0.2 W, 23 dBm) at LTE
• Supply voltage: 3.3 VDC +/– 9%
DW5580 specifications
General specifications
• Supported frequencies:
– GSM/GPRS/EDGE: 850, 900, 1800, 1900
– UMTS/HSPA: 800/850
1
, 900, AWS 1700, 1900, 2100 MHz
• Rx diversity
• 3GPP release 7 compliant
• SIM application Tool Kits 3GPP TS 51.014
• Built-in UDP/TCP/FTP/SMTP stack
• IP stack with TCP and UDP protocol
• Standard and extended AT command set
• Available variants: Data-only
1
Bands B6 and B19 (800 MHz) are a subset of B5 (850 MHz) and supported as well.
Data specifications
• HSPA category 6 in uplink and up to category 14 in downlink:
– Uplink up to 5.76 Mbps
– Downlink up to 21.0 Mbps
34
