PCI/PCIe
Configuration 1 PCI and PCI riser card PCI slot one PCI slot two
Maximum power 23W (3.3V x 3A + 5V x 1.5A + 12V x 0.5A), shared across
two slots
Configuration 2 PCIe and PCI riser card PCI slot one PCIe slot
Maximum power 23W (3.3V x 3A + 5V x 1.5A +
12V x 0.5A)
24W (12V x 2A)
Hard drives—HDD
General specifications
Type
5,400 RPM Hard Disk Drive
Capacity (GB)
NOTE: For hard drives, GB means 1 billion bytes;
actual capacity varies with pre-loaded material and
operating environment and will be less.
• 500 GB
• 1 TB
Dimensions inches (width x length x height)
• 500 GB: Approximately 70 x 100 x 7 mm (2.76 x 3.94 x
0.28 inches)
• 1 TB: Approximately 70 x 100 x 9.5 mm (2.76 x 3.94 x
0.37 inches)
Interface type and maximum speed Up to 6 GB/S (SATA 3.0)
MTBF
550,000 hours
Logical blocks
• 500 GB: 976,773,168
• 1 TB: 1,953,525,168
Power source
Power consumption (reference only) Idle 1.0 W, Active 3.10 W
Environmental operating conditions (non-condensing)
Temperature range
5°C to 60°C (41°F to 140°F)
Relative humidity range
5% to 90%
Op. shock (at 2ms)
350 G
Environmental non-operating conditions (non-condensing)
Temperature range
–40°C to 65°C (–40°F to 149°F)
Relative humidity range
5% to 95%
