Controller specifications
Bluetooth standards supported Bluetooth 4.1LE
Operating temperature –30ºC to 80ºC (–22ºF to 176ºF)
Operating system driver support Windows 7 32/64-bits, Windows 10 64-bits
Communications—WLAN antenna
General specifications
Antenna type PCB Dipole
Number of ports 2
Frequency (GHz) 2.4 to 2.5 4.9 to 5.9
Voltage Standing Wave Ratio (VSWR) 2:1 2:1
Isolation (dB) > 20 > 20
Peak gain 3.5 dBi 5.0 dBi
Average gain on sphere (3D) > –4 dBi > –5 dBi
Polarization Linear
Efficiency > 55% > 55%
Mechanical and environmental specifications
Height 105.60 mm (4.16 in)
Diameter 36.20 mm (1.43 in)
IPX class IP65
Mounting Wall mounted
Connector type SMA male
Antenna color White
Cable type Plenum rated low loss RG58
Cable color White
Mounting bracket Swivel type (plastic)
Mounting bracket length (approximate) 175 mm (6.89 in)
Mounting bracket color Black
Pig tail length 500 mm ± 10 mm (19.69 in ± 0.39 in)
Coaxial cable specification
Impedance 50 ± 2.00 ohms
Structural return loss –16 dB or better from 100-2500 MHz un-terminated sample
(direct bridge method)
Nominal RTL reference –16 dB or better to 6.0 GHz
Dielectric Foam FEP
Dielectric (outer diameter) 2.79 mm ± 0.076 mm (0.110 in ± 0.003 in)
Velocity of propagation 80%
