Coaxial cable specification
Center conductor Solid copper, 0.94 mm ± 0.025 mm (0.037 in ± 0.001 in)
Shield #1 Foil, aluminium/poly tape, adhered to dielectric
Diameter over foil 3.02 mm ± 0.07 mm (0.119 in ± 0.003 in)
Shield #2 Braid, 90% 36-AWG tin/copper
Outer jacket Plenum PVDF, off-white, lead-free, and UV stable
Outer diameter 4.52 mm ± 0.15 mm (0.178 in ± 0.006 in)
PLENUM rating CMP(ETL)C(ETL)
Attenuation dB/100 feet (nominal reference values)
• 8.0 dB at 450 MHz
• 12.5 dB at 900 MHz
• 19.6 dB at l.8 GHz
• 23.6 dB at 2.5 GHz
• 23.0 dB at 3.0 GHz
• 27.5 dB at 4.0 GHz
• 31.0 dB at 5.0 GHz
• 35.0 dB at 6.0 GHz
Installation temperature –20°C (–4°F) to +65°C (149°F)
Operating temperature –30°C (–22°F) to +65°C (149°F)
CC pullout 6 pound-force minimum, 16 pound-force maximum
Jacket pullout 4.5 pound-force minimum on 76.2 mm (3 in) section at 12.7
mm (0.5 in) per minute
Minimum bend radius 12.7 mm (0.5 in) static bend
Leakage –90 dB
Communications—Antenna 4-in-1
General specifications
Antenna type Pantheon antenna 4-in-1
Connector type 3m CFD-200 standard, fully customizable
Cable type SMA male straight, fully customizable
WLAN specifications
Frequency (GHz)
2.4~2.5 5.15~5.85
MIMO 1
Peak gain (dBi)
*
2.82 4.11
Average gain (dBi)
*
–3.43 –4.92
Efficiency (percent)
*
45.56 32.26
Return loss (dB)
*
< –10
MIMO 2
