Electrical specifications
• Output power:
– Class 4 (2 W, 33 dBm) at GSM 850/900
– Class 1 (1 W, 30 dBm) at GSM 1800/1900
– Class 3 (0.25 W, 24 dBm) at UMTS
– Class E2 (0.5 W, 27 dBm) at EDGE 850/900
– Class E2 (0.4 W, 26 dBm) at EDGE 1800/1900
• Supply voltage: 3.3 VDC +/– 9%
• Sensitivity:
– 108 dBm at UMTS
– 107 dBm at GSM 850/900 MHz
– 106 dBm at DCS1800/PCS1900 MHz
Communications—WWAN antenna
General specifications
Antenna
type
PCB dipole
Number of
ports
2
Frequency
(MHz)
698-803 791-862 824-894 880-960 1710-1880 1850-1990 1710-2155 1920-2170 2500-2690
VSWR 2:1
Isolation
(dB)
> 15
Peak gain < 5.0 dBi < 5.0 dBi < 5.0 dBi < 3.7 dBi < 5.0 dBi < 3.3 dBi < 3.3 dBi < 5.0 dBi < 5.0 dBi
Average
gain on
sphere (3D)
> –3 dBi
Polarization Linear
Efficiency
> 40%
Mechanical and environmental specifications
Height 254 mm (10 in)
Diameter 41 mm (1.61 in)
Weight 820 g (with mounting holder)
IPX class IP65
Mounting Wall mounted
Connector type SMA male
Antenna color White
Cable type Plenum rated low loss RG58
Cable color White
Mounting bracket Swivel type (plastic)
Mounting bracket length (approximate) 175 mm (6.89 in)
