Dell Embedded Box PC 5000 - Hard Drives-SSD; Canbus Port

Hard drives—SSD
General specifications
Type
• M.2 2260 SATA SSD
• M.2 2280 SATA SSD
Capacity (GB)
NOTE: For hard drives, GB means 1 billion bytes;
actual capacity varies with pre-loaded material and
operating environment and will be less.
• 32 GB
• 64 GB
• 128 GB
Dimensions (width x length x height)
• M.2 2260: Approximately 22 x 60 x 3.65 mm (0.87 x 2.36
x 0.14 in)
• M.2 2280: Approximately 22 x 80 x 3.65 mm (0.87 x 2.36
x 0.14 in)
Interface type and maximum speed Up to 6 GB/S (SATA 3.0)
MTBF
1,200,000 hours
Logical blocks
• 32 GB: 62,533,296
• 64 GB: 125,045,424
• 128 GB: 250,069,680
Power source
Power consumption (reference only) Idle 0.5 W, Active 2.5 W
Environmental operating conditions (non-condensing)
Temperature range
–40°C to 85°C (–40°F to 185°F)
Relative humidity range
10% to 90%
Op. shock (at 2ms)
1,500 G
Environmental non-operating conditions (non-condensing)
Temperature range
–40°C to 85°C (–40°F to 185°F)
Relative humidity range
5% to 95%
CANBus port
General specifications
Type D-SUB 9P connector contact EMUC-B201
Processor NXP LPC1756
Transceiver TI ISO 1050
CAN signals 2500 V galvanically-isolated
CAN activity Indicated by green LED on module
