Mechanical and environmental specifications
Mounting bracket color Black
Pig tail length 500 mm (19.69 in)
Coaxial cable specification
Impedance 50 ± 2.0 ohms
Structural return loss –16 dB or better from 100-2500 MHz un-terminated sample (direct
bridge method)
Nominal RTL reference –16 dB or better to 6.0 GHz
Dielectric Foam FEP
Dielectric (outer diameter) 2.79 mm ± 0.076 mm (0.110 in ± 0.003 in)
Velocity of propagation 80%
Center conductor Solid copper, 0.94 mm ± 0.025 mm (0.037 in ± 0.001 in)
Shield #1 Foil, aluminium/poly tape, adhered to dielectric
Diameter over foil 3.02 mm ± 0.07 mm (0.119 in ± 0.003 in)
Shield #2 Braid, 90% 36-AWG tin/copper
Outer jacket Plenum PVDF, off-white, lead-free, and UV stable
Outer diameter 4.52 mm ± 0.15 mm (0.178 in ± 0.006 in)
Outer Jacket Plenum PVDF, Off-white, lead free, and UV stable
Outer Diameter 4.52 mm ± 0.15 mm (0.178 in ± 0.006 in)
PLENUM rating CMP(ETL)C(ETL)
Attenuation dB/100 feet (nominal reference
values)
• 8.0 dB at 450 MHz
• 12.5 dB at 900 MHz
• 19.6 dB at l.8 GHz
• 23.6 dB at 2.5 GHz
• 23.0 dB at 3.0 GHz
• 27.5 dB at 4.0 GHz
• 31.0 dB at 5.0 GHz
• 35.0 dB at 6.0 GHz
Installation temperature –20°C (–4°F) to +65°C (149°F)
Operating temperature –30°C (–22°F) to +65°C (149°F)
CC pullout 6 pound-force minimum, 16 pound-force maximum
Jacket pullout 4.5 pound-force minimum on 76.2 mm (3 in) section at 12.7 mm (0.5
in) per minute
Minimum bend radius 12.7 mm (0.5 in) static bend
Leakage –90 dB
