NOTE: You must use a mini DP dongle to connect the enclosure to a VGA display.
PowerEdge MX modules ports and connectors
PowerEdge MX740c
Table 29. PowerEdge MX740c externally accessible connectors
Connector Description
USB ports
One USB 3.0-compliant port on the front of the sled.
One USB 3.0-compliant internal port.
One micro USB 2.0-compliant port for iDRAC Direct on the front of the sled.
NOTE: The micro USB 2.0-compliant port on the front of the sled can only be used as an iDRAC Direct
port.
PowerEdge MX840c
Table 30. PowerEdge MX840c externally accessible connectors
Connector Description
USB ports
One USB 3.0-compliant port on the front of the sled.
One USB 3.0-compliant port internal port.
One micro USB 2.0-compliant port for iDRAC Direct on the front of the sled.
NOTE: The micro USB 2.0-compliant port on the front of the sled can only be used as an iDRAC Direct
port.
MX7116n Fabric Expander Module
Table 31. MX7116n Fabric Expander Module externally accessible connectors
Connector Description
Externally accessible
connectors
2 QSFP28-DD connections to the MX7116n
MX9116n Fabric Switching Engine
Table 32. MX9116n Fabric Switching Engine externally accessible connectors
Connector Description
Externally accessible
connectors
12 QSFP28-DD ports that can be configured as:
2 x 40 GbE or 2 x 100 GbE ports for uplinks
8 x 10 GbE or 8 x 25 GbE ports for rack servers
2 QSFP28 uplink ports that can be configured as:
1 x 40 GbE
1 x 100 GbE
2 x 50 GbE
4 x 10 GbE
4 x 25 GbE
2 QSFP28 unified ports that can be configured as:
1 x 40 GbE
Technical specifications 77
