Dell EMC PowerEdge MX7000 Service Manual

Table 32. MX9116n Fabric Switching Engine externally accessible connectors
Connector Description
○ 1 x 100 GbE
○ 2 x 50 GbE
○ 4 x 10 GbE
○ 4 x 25 GbE
○ 8 x 8/ 16/ 32 GbE Fibre Channel mode
MX9002m Management Module
Table 33. MX9002m Management Module externally accessible connectors
Connector Description
Externally accessible
connectors
● Two x 1G-BaseT Ethernet ports
● One x Micro-B USB port
MX5108n Ethernet Switch
Table 34. MX5108n Ethernet Switch externally accessible connectors
Connector Description
Externally accessible
connectors
● 2 x 100 GbE QSFP28 uplink ports
● 1 x 40 GbE QSFP+ uplink port
● 4 x 10GBASE-T uplink ports
● USB Serial and USB Flash ports
MXG610s Fibre Channel Switch
Table 35. MXG610s Fibre Channel Switch externally accessible connectors
Connector Description
USB port One micro USB 2.0-compliant port on the front of the sled.
Fibre Channel transceiver 16 external ports supporting 8/ 16/ 32 Gbps speeds using 8 SFPs and 2 QSFPs.
PowerEdge MX 10GBASE-T Ethernet Pass-Through Module
Table 36. PowerEdge MX 10GBASE-T Ethernet Pass-Through Module externally accessible connectors
Connector Description
Fibre Channel transceiver 16 external ports supporting 10 GbE connections
PowerEdge MX 25 Gb Ethernet Pass-Through Module
Table 37. PowerEdge MX 25 Gb Ethernet Pass-Through Module externally accessible connectors
Connector Description
Fibre Channel transceiver 16 external ports supporting 25 GbE connections
78 Technical specifications

Dell EMC PowerEdge MX7000 Specifications

General

Form Factor	Modular Enclosure
Power Supplies	Up to 6 hot-plug power supply units (PSUs)
Management	Dell EMC OpenManage Enterprise Modular Edition
Enclosure Type	Modular Enclosure
Number of Slots	8 slots
Maximum Number of Compute Sleds	8
Maximum Number of Storage Sleds	8
Maximum Number of Fabric Switching Modules	8
Management Module Slots	2
