Dell EMC Virtual Edge Platform 1405 Series User Manual

Table 5. Back view system status indicator LED behavior
Class Behavior
1000M Base-T LED
● Link LED - Green or amber
○ Solid green - Port is linked and running at maximum 1000M
speed on Base-T port
○ Solid amber - Port is linked and running at lower 100M or 10M
speed on Base-T port
○ Off - No link
● Activity LED - Green
NOTE: The LED flashes green during port activity.
○ Off - no port activity
SFP+ LED
● Link LED - Green or amber
○ Solid green - Port is linked and running at 10G speed
○ Solid amber - Port is linked and running at 1G speed
○ Off - No link
● Activity LED - Green
NOTE: The LED flashes green during port activity.
○ Off - no port activity
Table 6. Reset button behavior
Action Behavior
Press the Reset button for less than 5 seconds:
● System reboots
Press the Reset button for more than 5 seconds:
● System reboots and system is reset to factory defaults
● Status indicator LED color changes to blue
● Flag indicating a long push is set by the BIOS in the CMOS RAM
● Flag allows user to have the operating system detect a long button
push
Table 7. Chassis physical design
Parameter Configuration option 1 Configuration option 2
Height 5.2 cm (2.0 in) 5.2 cm (2.0 in)
Width 20.8 cm (8.1 in) 20.8 cm (8.1 in)
Depth 20.0 cm (7.9 in) 20.0 cm (7.9 in)
Chassis weight with factory-
installed components
● 4-core: 1.44 kg (3.17 lb)
● 8-core: 1.42 kg (3.13 lb)
● 16-core: 1.44 kg (3.17 lb)
● 8-core: 1.42 kg (3.13 lb)
● 16-core: 1.44 kg (3.17 lb)
NOTE: Chassis weight does not include the weight of the power supply.
Table 8. Environmental parameters
Parameter Configuration option 1 Configuration option 2
Operating temperature 0–40°C (32°F–104°F) continuously 0–40°C (32°F–104°F) continuously
Operating humidity
● 5% to 85% (RH), noncondensing
continuously
● 5% to 90% (RH), noncondensing short-
term (< 1% of operational hour per year)
● 5% to 85% (RH), noncondensing
continuously
● 5% to 90% (RH), noncondensing short-
term (< 1% of operational hour per year)
Storage temperature –40°-70°C (–40° to 158°F) –40°-70°C (–40° to 158°F)
Storage humidity 5% to 90% (RH), noncondensing 5% to 90% (RH), noncondensing
8 Introduction
