Table 23. BOSS S2 module kit components (continued)
T350 (quantity) Components in kit
1 BOSS signal cable
1 BOSS power cable
1 BOSS-S2 module
1 or 2* BOSS-S2 card carrier
1 or 2* M.2 SSD
2 M.2 240 GB information label
2 M.2 480 GB information label
1 BOSS card filler
1 Tech sheet
To remove the BOSS blank :
1. Power off the system and remove the system cover.
2. Loosen the captive screw and pull out the BOSS module S2 blank form the system bay.
Figure 102. Removing the BOSS S2 module blank
To install the BOSS blank:
1. Align and slide the BOSS S2 module blank into the system bay.
2. Hold the BOSS S2 module blank into its place and tighten the captive screw.
