Figure 103. Installing the BOSS S2 module blank
To install the BOSS S2 module:
1. Install the BOSS S2 module . To install the BOSS S2 , see installing the BOSS S2 module steps 1 to 3.
2. Install the M.2 SSD. To install the M.2 SSD, see installing the BOSS S2 module steps 4 to 8.
NOTE:
Installing the BOSS S2 card carrier does not require the system to be powered off. System shutdown is only
required when installing the BOSS S2 controller card module.
To remove the BOSS S2 controller card module:
1. Power off the system and remove the system cover.
2. Remove the M.2 SSD. To remove the M.2 SSD, see removing the BOSS S2 module steps 1 to 4.
3. Remove the BOSS S2 module. To remove the BOSS S2 controller card module, see removing the BOSS S2 module steps 5
to 7.
4. Install the BOSS S2 module blank.
NOTE:
Removal of the BOSS S2 card carrier does not require the system to be powered off. System shutdown is only
required when removing the BOSS S2 module.
NOTE: Disconnect the BOSS signal cable and the BOSS power cable before lifting the module from the system.
114 Upgrade Kits
