Removing the power-button
module
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover.
2 Remove the wireless card.
3 Remove the computer base.
4 Remove the back cover.
Procedure
1 Remove the screw that secures the power-button cable to the middle
cover.
2 Note the power-button cable routing and remove it from the routing
guides.
3 Disconnect the power-button cable from the control-buttons board
cable.
4 Peel off the tape that covers the power-button module.
73
